  • AGM Rattler TS35-384 Compact Medium Range Thermal Imaging Rifle Scope 384x288 (50 Hz), 35 mm lens.
  • AGM Rattler TS35-384 Compact Medium Range Thermal Imaging Rifle Scope 384x288 (50 Hz), 35 mm lens.
  • AGM Rattler TS35-384 Compact Medium Range Thermal Imaging Rifle Scope 384x288 (50 Hz), 35 mm lens.
  • AGM Rattler TS35-384 Compact Medium Range Thermal Imaging Rifle Scope 384x288 (50 Hz), 35 mm lens.
  • AGM Rattler TS35-384 Compact Medium Range Thermal Imaging Rifle Scope 384x288 (50 Hz), 35 mm lens.

    • AGM Rattler TS35-384 Compact Medium Range Thermal Imaging Rifle Scope 384x288 (50 Hz), 35 mm lens.

    AGM

    MSRP: $2,620.00
    $2,095.00
    (You save $525.00 )
    SKU:
    3092455005TH31

    Currently Out of Stock - Please Call for Availability 309-781-8421

    Product Description

    DESCRIPTION AND FEATURES

    The AGM Rattler TS25-384 and Rattler TS35-384 are the compact thermal imaging scopes developed for 24 hours operation under any weather and environmental conditions. Two objective lens options allow the customer to choose perfect unit for your needs where 25 mm lens designed for short range shooting, while the 35 mm lens model will be great for medium range missions.Thermal image riflescope has 384×288 thermal detector and 1024×768 OLED monitor, which provides clear image under harsh environment conditions like darkness, fog, smoke, dust, rain, snow, wood, camouflage, etc. The device is used as a thermal rifle scope or handheld monocular. The scope is mainly applied to scenarios such as patrolling, and hunting, etc.Powered with two CR123 batteries the AGM Rattler TS-384 gives up to 4.5 hours of continuous operation time. An external 5V power bank (battery pack) can be easily connected via a USB connector for a significant increase of operating time. Onboard Wi-Fi module for live video streaming and video/images recording via application are also available.

    384 × 288 thermal resolution, high sensitivity detector

    Image processing technology: Adaptive AGC, DDE, 3D DNR

    1024 × 768 resolution 0.39-inch OLED display

    8x digital zoom

    Video recording and snapshot, built-in EMMC (16 GB)

    Supports distance measurement

    Adjustable color palettes

    Wi-Fi data transmission

    Waterproof, shockproof

    Up to 4.5 hours continuous working

    External power supply capability

    Limited 3-year warranty

    Downloads

    Data Sheet

    User Manual

    SPECIFICATIONS

    Shock and vibration: 750 g/ms

    Detector type: 17μm, Uncooled, 50Hz

    Standby Mode:Yes

    Resolution:384x288

    Detection Range: Max. 1235 m

    Snapshot: Yes

    Lens system:35 mm; F/1.0

    Optical magnification: 2.14xField of view (H × X)10.0° x 8.0°

    Digital zoom: 2x, 4x, 8x,

    PIP

    Eye relief: 45 mm

    Imaging palettes: Jungle, Recognition

    Display: 0.39-inch, OLED, 1024 × 768

    StorageBuilt-in EMMC (16 GB)

    Record Video: Yes

    Battery Type: Two CR123

    Wi-Fi: Yes

    Battery Life (Operating): Up to 4.5 hr

    External power supply: 5V USB

    Operating Temperature Range: -20°C to +55°C (-4°F to +131°F)

    Degree of Protection: IP67

    Weight: 0.41 kg ( 0.91 lb)

    Overall Dimensions: 187.2 × 62.5 × 59.2 mm (7.37 × 2.46 × 2.33 in)


    AGM Rattler TS35-384 Thermal Imaging Rifle Scope 35mm lens.
