AGM Rattler TS35 640

DESCRIPTION AND FEATURES

AGM Rattler TS35-640 thermal scope is the compact thermal imaging scope developed for 24 hours operation under any weather and environmental conditions. This rifle scope with 35 mm Germanium lens is perfect unit for medium range shooting.
Thermal image riflescope has 640×512, 12μm thermal detector with 50 Hz refresh rate and 1024×768 OLED monitor, which provides clear image under harsh environment conditions like darkness, fog, smoke, dust, rain, snow, wood, camouflage, etc. The device is used as a thermal rifle scope or handheld monocular.  The scope is mainly applied to scenarios such as patrolling, hunting, etc.
Powered with two CR123 batteries the AGM Rattler TS35-640 gives up to 4.5 hours of continuous operation time. An external 5V power bank (battery pack) can be easily connected via a USB connector for a significant increase of operating time. Onboard Wi-Fi module for live video streaming and video/images recording via application are also available.

Warning: California's Proposition 65

• 640×512 thermal resolution
• 12 μm, 35 mK NETD high sensitivity detector
• Fast 50Hz imaging
• 1024×768 resolution, 0.39-inch OLED display
• 2x optical magnification
• 1x, 2x, 4x, 8x digital zoom
• Digital image processing technology
• Video recording and snapshot, built-in EMMC (16 GB)
• Various reticle types and colors
• Stadiametric rangefinder
• Adjustable color palettes
• Wi-Fi data transmission
• Standby mode
• Waterproof, shockproof
• Up to 4.5 hours continuous working
• External power supply capability
• Limited 3-year warranty

CHARACTERISTICS:

Detector type: 12μm, Uncooled, 50 Hz

Refresh rate: 50 Hz

Resolution: 640x512

FOV: 12.5° × 10.0°

PACKAGE INCLUDES

• Lens Tissue
• Operators Manual
• Packing Box
• USB Cable
• Soft Carrying Case

DOWNLOADS

Data Sheet

EXPORT RESTRICTIONS:

Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.

SPECIFICATIONS

Palettes - Black Hot, White Hot, Red Hot, Fusion

Reticle - 5 types, 4 colors, on/off

Drop Test Height - 1.5m (4.9 feet)

Boresight Adjustment - Digital Controlled

Distance Measurement - Yes (Stadiametric Rangefinder)

Scene Mode - Jungle, Recognition

Picture In Picture Mode (PIP) - Yes (2× Zoom)

Video Recording - Yes

Defective Pixels Correction (DPC) - Yes

Uniformity Correction - Auto, Manual, External Correction

Observation Distance - 1,750 m

Detector type - 12μm, Uncooled, 50 Hz

Standby Mode - Yes

Resolution - 640 × 512

Lens system - 35 mm; F/1.0

Optical magnification - 2x

Field of view (H × X) - 12.5° × 10.0°

Digital zoom - 1×, 2×, 4×, 8×

Eye relief - 45 mm

Display - 0.39-inch, OLED, 1024×768, 50 Hz

Storage - Built-in EMMC (16 GB)

Battery Type - Two CR123 (3V) Lithium or two RCR123 (up to 4.2V) Rechargeable Batteries

CVBS Output - Yes (via USB)

Battery Life (Operating) - Up to 4.5 hr

External power supply - 5 VDC/2 A, USB Type-C interface

Operating Temperature Range -20°C to +55°C (-4°F to +131°F)

Degree of Protection - IP67

Weight - 480 g ( 1.06 lb)

Overall Dimensions - 187 × 62 × 59 mm (7.4 × 2.5 × 2.3 in)

Package Includes - Thermal Imaging Rifle Scope, Mount, USB Cable, Lens Cloth, Manual
