HALO XRF is N-Vision Optics latest groundbreaking product that combines state of the art BAE thermal imaging CORE with top customer demanded features, such as integrated laser range finder, onboard video recording, and WiFi connectivity. HALO-XRF is proudly designed and built in the USA, making it the ultimate US-made thermal scope with integrated LRF available to the hunting market.
BAE 640 x 480, 12 um, 60 Hz Thermal Imaging Core
Built-in Laser Range Finder, Video and Audio Recording
50 mm F1.1 Germanium objective lens
8 Reticle Options
Built-in Video and Audio Recording
HALO-XRF eliminates the need for external recorders. Pixel accurate 60 Hz videos are internally captured and stored for later transfer to the user’s PC via USB connection.
Streaming
The streaming feature permits the user to stream videos over the WiFi connection and possibly broadcast the hunts in real-time to Youtube, Facebook, or any other social media if it is still allowed and available.
Laser Range Finder
HALO-XRF features a built-in laser range finder with a range of up to 1,000 yards/meters.
Rechargeable 18650 Batteries
HALO-XRF operates on two rechargeable 18650 batteries, providing up to 7 hours of run time (at room temperature).
Zoom Sensitive Zeroing
Reticle movement steps are zoom dependent, which allows for the most precise zeroing.
Reticles
Eight reticle choices with two Mil Dot reticles.
USB-C Connector
Standard USB-C type cable is used for user software updates, downloading videos and still images, or powering up the HALO-XRF with an external 5V (USB) power source.
Specifications:
Sensor Pixel Pitch: 12 um
Resolution: 640 x 480
Refresh Rate: 60 Hz
Lens: 50mm F1.1
Focus: Fixed
Digital Zoom: 1x/2x/4x/8x
Magnification: 3.5x
Display Type: OLED 640×480 B&W
Power: two 18650 batteries
Remote power: USB 5.0V
External connector: Waterproof USB-C
Calibration (NUC): Manual
Detection range: 2020 yards
Recognition range: 726 yards
Identification range: 380 yards
Weight: 37 oz
Size: 8.9 × 3.6 ×3.4 inches
Weight: 32.5 oz
Size: 8.6 x 3.6 x 3.4 inches
If you'd otherwise buy a scope and a separate rangefinder, it makes sense. The HALO-XRF combines a 640 BAE core, a 50mm lens and a 1,000-yard laser rangefinder, and records video onboard. If you never range past what you can judge by eye, the HALO-X50 keeps the 50mm lens size without the LRF.
In night vision, halo is the bright ring that forms around a light source in an image intensifier tube. The HALO-XRF is a thermal scope, so it doesn't use an intensifier tube and HALO is just N-Vision's name for the line. You see heat on a 640x480 OLED display instead.
Most hunters zero a thermal at 50 or 100 yards, matched to where most of their shots happen. The HALO-XRF has zoom-sensitive zeroing, so the zero holds as you step through 1x, 2x, 4x and 8x, and its built-in rangefinder tells you how far past your zero a coyote is standing.
