AGM FUZION TM25-384
MSRP:
$2,200.00
DNO PRICE:
$2,200.00
For a Limited Time
$2,095.00
You save $105.00
Free shipping on orders over $399*- No sales tax outside Illinois
No card fees and 2% off when you pay by e-check
Hunters on the phone to help you choose
Goes with this AGM
Overview
DESCRIPTION AND FEATURES
The AGM Fuzion Handheld Thermal & Optical Bi-spectrum Monocular is equipped with 12μm high sensitivity thermal detector, ultra-low light optical detector, 1024×768 OLED display and eyepiece with a large field of view. The device can quickly detect hiding objects even under extreme environments such as smoke, fog, rain, snow, etc. It can be widely applied to scenarios including patrol, search and rescue, drug interdiction, and suspect apprehension. Due to its waterproof capability the device performs well even in severe weather conditions and challenging environments.
The Fuzion’s user-friendly interface, comfortable and ergonomic operating controls makes adoption and application incredibly simple. The monocular offers three different variants of image view: thermal, visible light, and fusion that can be easily adapted depending on different environmental conditions. The Fuzion uses one 18650 rechargeable Lithium battery for up to 5-hours of operating time. In addition, an external power supply can be used to provide an increase in operating time.
Warning: California's Proposition 65
- Bi-spectrum image fusion and object highlight
- Detail enhancement and target recognition
- Selection of thermal view channel, visible light channel, or both them combined
- 12 μm, 35 mK NETD high sensitivity thermal detector
- Fast 50 Hz imaging
- 1x, 2x, 4x, 8x digital zoom
- Digital image processing technology
- Ultra-low illumination optical channel
- 1920×1080 Optical resolution
- 1024×768 resolution, 0.39-inch OLED display
- Video recording and snapshot, built-in EMMC (16 GB)
- Wi-Fi hotspot
- Standby mode
- Up to 5 hours continuous running
- Waterproof
- Limited 3-Year Warranty
CHARACTERISTICS
Detector type: 12 μm VOx Uncooled Focal Plane Arrays
Refresh rate: 50 Hz
Resolution: 384 × 288
FOV: 10.5° × 7.9°
DOWNLOADS:
Data Sheet
EXPORT RESTRICTIONS:
Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.
SPECIFICATIONS
Wavelength - Optical Sensor Wavelength 400-1000 nm
Palettes - Black Hot, White Hot, Red Hot, Fusion, Visible, Image Fusion
Scene Mode - Jungle, Recognition
Hotspot - Yes
Observation Distance - 1x, 2x, 4x, 8x
Detector type - 12 μm VOx Uncooled Focal Plane Arrays
Image sensor - Optical Image Sensor 1/2” Progressive Scan CMOS, 1960×1200@25fps
Response Waveband - 8 μm to 14 μm
FFC (Flat Field Correction) - Auto, Manual, External Correction
Highest Temperature Spot Tracking - Yes
Standby Mode - Yes
Refresh rate - 50 Hz
Aperture - F1.0
Resolution - 384 × 288
Optical magnification - 2.5x – 20x
Lens (focal length) - Optical Module Lens Focal Length - 22mm Thermal Lens Focal Length - 25mm
Power - 5 VDC/2 A, USB Type-C interface Supports external power supply
Field of view (H × X) - 10.5° × 7.9°
Digital zoom - 1x, 2x, 4x, 8x
Monitor - 1024x768, 0.39 inch, OLED, 50Hz
Storage - Built-in 16 GB EMMC
Record Video - On-board video recording
Capture Snapshot - Yes
Battery Type - One 18650 rechargeable battery (removable)
CVBS Output - Yes (via USB)
Battery Operating Time - Up to 5 hours continuous running (@25°C, WiFi and CVBS off) Up to 3 hours continuous running (@25°C, WiFi and CVBS on)
Battery Capacity Display - Yes
Operating Temperature Range -20°C to 55°C (-4°F to 131°F)
Weight - 470 g (1.04 Ib)
Overall Dimensions - 161 × 87 × 51 mm (6.3 × 3.4 × 2.0 in)
Protection Level - IP67 (Waterproof)
Specs
- Brand
- AGM
- SKU:
- 3142451004FM21
Frequently Asked Questions
Are AGM thermal monoculars like the Fuzion TM25-384 any good?
AGM builds solid hunting thermals, and this Fuzion is a good example. It pairs a sensitive 35 mK thermal sensor with a low-light camera, records to 16 GB of storage, and carries an IP67 rating. Our customers have left around 1,000 reviews, and real people here can walk you through it on the phone.
Is the Fuzion TM25-384 a good value for the money?
It is the way into fusion viewing without paying for a rangefinder you may already own. You still get the thermal and optical channels, the 1024x768 OLED and the same 18650 battery the LRF version uses. PayPal Credit is available, with no interest if paid in full within 6 months, subject to approval.
Is the Fuzion TM25-384 a good thermal monocular to buy in 2026?
It is a strong pick if you want fusion viewing and plan to use a separate rangefinder. The 25 mm lens favors wide scanning over long reach. If you would rather have ranging built in, look at the Fuzion LRF TM25 384, which shares the same sensor resolution and field of view.
