Product Description
Main
Sensor = 384x288 pix. @ 17 µm (NETD <25 mK)
Objective lens = F50 F/1.0
Magnification = 3-12x
Field of view (HxV) = 7.5/13.1 degrees / m@100m
Detection range = 1800m
Sensor
Type = uncooled
Resolution = 384x288pixels
Pixel pitch = 17µm
NETD = <25 mK
Frame rate = 50Hz
Optics
Objective lens = F50 F/1.0
Magnification = 3-12x
Field of view (HxV): 7.5/13.1 degrees / m @ 100 m
Eye relief = 50mm
Display
Type = AMOLED
Resolution = 1024x768 pixels
Range Performance
Detection range = 1800 m
Reticle
Click value, H/V =13 – 3x, 6.5 – 6x, 3.25 – 12x mm at 100 m
Click range, H/V = = 2600/2600mm at 100 m
Number of preloaded reticles = 10
Video Recorder
Video / photo resolution = 1024х768 pixel
Video / photo format = .mp4 / .jpg
Built-in memory = 16GB
Wi-Fi
Wireless Protocol = Wi-Fi
Wireless Standard = 802.11 b/g/n/ac
Frequency = 2.4 / 5 GHz
Environmental Characteristics
Degree of protection = IPX7 IP code (IEC60529)
Operating temperature range = -25 – +50 С
Connections and Compatibilities
Max. recoil power on rifled weapon (Eo) = 6000 Joules
Shock resistance on the smooth-bore rifles = 12 caliber
Compatible mounts = Standard 30 mm rings
Supported Application = Stream Vision 2
Power Supply
Output voltage = 3.0–4.2V
Battery type = Li-Ion Battery Pack АPS2 (external), Li-Ion Battery Pack APS3 (external)-sold separately*, Li-Ion Battery Pack APS5 (internal)
Capacity = 2000 (external) + 3200 (external)* + 4900 (internal) mAh
Operating time on battery pack (at t=22°C)= 10h *
External power supply = 5V, 9V (USB Type-C Power Delivery)
Weight & Size
Body material = Metal
Dimensions = 412x78x83mm
Weight = 0.9kg
